Основна информация
| Производител | TUNCMATIK |
|---|
| Part Number | TSK5208 |
|---|
| EAN / Код | LITE II 1000VA Line-interactive |
|---|
| Гаранция | 24 месеца |
|---|
| Ключови характеристики | TUNCMATIK UPS LINE INTERACTIVE 1000VA SIMULATED SINE WAVE 4xSCHUKO |
|---|
Технически характеристики
| Vendor_url | https://www.tuncmatik.com/en/product/technic-specs/lite-ii-1000va.html |
|---|
| Part number / Product code | TSK5208 |
|---|
| Model | Lite II 1000 VA |
|---|
| Type | Line-interactive |
|---|
| Capacity | 1000 VA / 600 W |
|---|
| Input | Voltage:220 / 230 / 240 VAC; Voltage range:162-265 VAC; Frequency:50 / 60 Hz ± 10%. |
|---|
| Output | Voltage:220 VAC; Voltage range:± 10%; Frequency range (Synchronized):50 / 60 Hz ± %4; Frequency range (Battery mode):50 ± 0.25 Hz - 60 ± 0.3 Hz; Transfer time:2 - 6 msec, 10 msec max.; Waveform:Simulated sine wave. |
|---|
| Battery | Type & number of battery 12V 7Ah x 2 Charge time 4-6 hours for recharging up to 90% capacity Charge voltage 27.0 VDC Charge current 1.0 A |
|---|
| Display | LED Panel |
|---|
| Alarms | LED indicator:AC mode, Battery mode, Fault conditions; Alarm:Battery mode, Low battery, Overload, Fault. |
|---|
| Environment | Operating temperature:0-40°C; Humidity: 20-90% RH (non-condensing); Noise level (audible):< 40 dBA. |
|---|
| Weight | 8 kg |
|---|
| Dimensions | 392 x 179 x 209mm |
|---|
| Warranty | 24 Months |
|---|
Наличност: Артикулът е наличен по заявка от Външен склад. Свържете се с нас.
| Технически характеристики |
| Alarms | LED indicator:AC mode, Battery mode, Fault conditions; Alarm:Battery mode, Low battery, Overload, Fault. |
| Battery | Type & number of battery 12V 7Ah x 2 Charge time 4-6 hours for recharging up to 90% capacity Charge voltage 27.0 VDC Charge current 1.0 A |
| Capacity | 1000 VA / 600 W |
| Dimensions | 392 x 179 x 209mm |
| Display | LED Panel |
| Environment | Operating temperature:0-40°C; Humidity: 20-90% RH (non-condensing); Noise level (audible):< 40 dBA. |
| Input | Voltage:220 / 230 / 240 VAC; Voltage range:162-265 VAC; Frequency:50 / 60 Hz ± 10%. |
| Model | Lite II 1000 VA |
| Output | Voltage:220 VAC; Voltage range:± 10%; Frequency range (Synchronized):50 / 60 Hz ± %4; Frequency range (Battery mode):50 ± 0.25 Hz - 60 ± 0.3 Hz; Transfer time:2 - 6 msec, 10 msec max.; Waveform:Simulated sine wave. |
| Part number / Product code | TSK5208 |
| Type | Line-interactive |
| Vendor_url | https://www.tuncmatik.com/en/product/technic-specs/lite-ii-1000va.html |
| Warranty | 24 Months |
| Weight | 8 kg |
